Collision Devices Nocturnal Shimmer Delay/Tremolo Pedal

Condition Note: Minor cosmetic blemishes, damage to original packaging.

DUSK
Modulated Delay. Warmed and inspirational delay based on a tape delay circuit.

Settings:

• Mix: Controls the mix between Full Dry or 50% Dry / 50% Wet
• Time: Time between each repetition. From a few ms to 1 second. Signal quality turns to Lo-Fi when it’s pushed to long repeats.
• Feedback: Number of repetitions. Able to self oscillate very easily when the knob is around 7.5.
• Modulation: Amount of modulation in the delay repetitions. Create a sort of old tape effect
• Speed: Modulation’s frequency from 0.1 to 20 Hz.

NIGHT
Dynamic Tremolo. Turn a huge amount of shimmer and reverb into it to make it oscillate faster.

Settings:

• Sens: Sensibility, turn it clockwise to make the tremolo more sensitive to your attack
• Depth: Controls the tremolo’s volume

DAWN
Shimmer. Create bright soundscapes and loose the notion of time until the sunrise.

Settings:

• Blend: Controls the amount of Dry/Wet signal. You can have a full Wet reverb.
• Reverb: Reverberation time. Max 15 sec.
• Shimmer: Makes the reverb shimmer
• Filter: Digital filter. Low pass. Lets you make the shimmer darker or more shiny
• Colour: Bandpass active and analog filter around 3.3 kHz. Controls the Q of the filter.

Maximum current draw: 250 mA
Imput Impedance: 1 MOhm
Size: 119 x 116 x 56mm
Voltage: +9V DC (négative center)
Output Impedance: 10 KOhm
Weight: 700gr

• The use of an isolated power supply is recommended for powering all Collision devices Pedals.
• Power supply not included.
• The pedal is true bypass
